Main Features:

1. Positive and Negative coordinate processing.
2. With W axis for moving machine head to load
   high product
3. Programmable Z axis, 10 step, 99 program
   storage
4. Built in 3 axis Linear scale ( 1um or 5um)
5. Precision co-ordinate table on flat & V type turcide coated guide ways driven by ball screw
6. Double door and large working tank for ease of loading & unloading of workpiece
7. Oil level alarm, insufficient liquid level protection;
8. With the quill running on preloaded cross roller bearing and ball screw for accuracy working
9. High speed quill moment with Panasonic AC servo motor, more efficient than DC servo motor.
10. New generation superfine discharge ciruit for mirror surface
11. Hand held multi-function remote controller
12. Reverse servo machining
13. Automatic carbon deposition detection function, adjusts various processing parameters automatically
14. Special circuits for deep hole and large area electrode processing
15. Self-diagnostic trouble shooting with alarm
16. Automatic lubrication system
17. Fire extinguisher, Smoke detector alarm
18. Power efficient high pressure dielectric pump
