Vertical

Machining Center

Main Features:

  1. Robust construction for efficient machining.
  2. HIWIN/PMI linear rail for XYZ, rapid moving speed
    can reach 36/48 m/min.
  3. NSK high-precision bearing preloaded for ball
    screws on all 3 axes.
  4. 24 Stations taiwan arm type of tool magazine
  5. The rotary table ( 4 or 5axis) as optional.
  6. 6. Integrated coolant system.
  7. Chip conveyor and purge system for optimum chip removal.
  8. Easy accessibility of work table for easy setup and tooling.
  9. Enclosed work space ensures safe and contamination-free work.
  10. Different Operating system as optional: Siemens, Fanuc,
    Mitsubishi,GSK,KND,Syntec.
