Main Features:

1. Multi-cut EDM Wire Cutting Machine (T series)
   Robust frame with “T” shape structure.

2. Long travel rail installed in the bottom, which imporve the
   stability for heavy product.

3. With height adjustable diamond guider.

4. Four axes independent (X/Y/U/V) work, with Taiwan linear and
   ball screw.

5. Special Tensioning mechanism for molybdenum wire, keep stable cutting.

6. Stepper motor is standard, Servo motor is optional.
7. Tolerance can keep in +/-0.006mm, Roughness Ra 0.8.
8. Full enclosed cover, Similar to European machine.
9. New Genration control cabinet, High efficient. ( max. cutting speed ≥ 180mm2/min)
