Main Features:

1. Bed, columns and travel tracks form a solid frame
   structure for high rigidity under hard machining
   conditions.
2. The oversized column combined with box type beam
   construction features additional machine rigidity.
3. The slant beam construction with increased slide way
   surfaces efficiently upgrades force distribution area
4. The spindle head is located at the center of beam, providing high movement
   accuracy, superior heavy cutting capability.
5. Equipped with spindle motor ball screw and double counter-balance cylinders are
   all properly located at the best positions.
6. Taiwan HIWIN linear rail for all XYZ axis.
7. Different Operating system as optional: FANUC, SIEMENS, GSK, LNC, SYNTEC.
